Analog cameras
for security and surveillance


Vicon offers a variety of cost-effective, high-resolution analog cameras designed to provide a superior picture quality. Our analog cameras have a wide range of features and capabilities for any application to bring the right solution for your specific needs.


network-cameras-overview-img-Surveyor-HD analog-cameras-overview-img-V660B-IR-bullet-camera-series analog-cameras-overview-img-V661-N-HR analog-cameras-overview-img-new-V662-D-2
Camera category PTZ Bullet Box Box
Model SurveyorVFT SVFT-23; SVFT-36 V660B-312IR-1;V660B-550IR V661-N-1 V662-D-2
Description PTZ camera dome; in-ceiling, outdoor, impact-resistant and pressurized versions; Outdoor/Impact: IP66, NEMA; Press: IP67; NTSC or PAL models Bullet camera with built-in IR illuminators; varifocal lens; OSD for setup with joystick control; privacy masks IP66 High resolution 1/3-in. format box camera with C/CS lens mount; OSD setup with joystick control; privacy masking and motion detection; NTSC/PAL versions High resolution 1/3-in. format box camera with C/CS lens mount; OSD setup with joystick control; privacy masking and motion detection; NTSC/PAL versions
Resolution 540 TVL 700 TVL 700 TVL 750 TVL
Lens 3.6-82.8 mm (23X);
3.3-119 mm (36X)
2.8-12 mm varifocal Can accept C or CS-mount lens; autoiris output connector Can accept C or CS-mount lens
Environmental Indoor: 32-132°F (0-55°C; );
Outdoor: -29-165°F (-34-74°C)
Outdoor: 14-122°F (-10-50°C) Indoor: 14-122° F (-10-50° C) Indoor: 14-122° F (-10-50° C)
Usage D/N; WDR; EIS (36X) D/N; IR D/N; WDR D/N; WDR
Power 18-30 VAC 24 VAC; 12 VDC 24VAC; 12VDC 24VAC; 12VDC
Explore more Explore more Explore more Explore more

analog-cameras-overview-img-Roughneck-V920D analog-cameras-overview-img-V661V analog-cameras-overview-img-V661V analog-cameras-overview-img-V661D
Camera category Dome Dome Dome Dome
Model Roughneck: V920D-N312 V661V-312N; V661V-312IR-1 V662V-312D-2 V661D-312N-1; V661D-312D-1
Description Camera dome with varifocal autoiris lens; privacy masks; heater; IP66; IK10; NTSC or PAL models Vandal-proof camera dome; 1/3-in. camera format; varifocal autoiris lens; privacy masks; IP66; NTSC or PAL models Vandal-proof camera dome; 1/3-in. camera format; varifocal autoiris lens; privacy masks; IP66; IK10; NTSC or PAL models Compact camera dome; 1/3-in. camera format; varifocal autoiris lens; privacy masks; IP66; IK10; NTSC or PAL models
Resolution 750 TVL 700/750 TVL 750 TVL 700/750 TVL
Lens 2.8-12 mm autoiris varifocal 2.8-12 mm autoiris varifocal 2.8-12 mm autoiris varifocal 2.8-12 mm autoiris varifocal
Environmental Indoor/Outdoor
With heater: -40-122°F (-40-50°C);
Without heater: 14-122°F (-10-50°C)
Outdoor: 14-122°F (-10-50°C) Outdoor: 14-122°F (-10-50°C) Indoor/Outdoor: 14-122°F (-10-50°C)
Usage D/N; D-WDR D/N; IR (select model) D/N; WDR D/N; D-WDR
Power 24 VAC; 12 VDC 24 VAC; 12 VDC 24 VAC; 12 VDC 24 VAC; 12 VDC
Explore more Explore more Explore more Explore more

Camera compatibility

ViconNet-logo-70

psia-big-logo-70

Onvif-big-logo-70

Vicon cameras can be integrated with a ViconNet surveillance system, including ViconNet VMS and NVRs.

Vicon cameras are PSIA compliant and can be integrated with most leading NVR and VMS platforms.

Vicon cameras are ONVIF compliant and can be integrated with most leading NVR and VMS platforms.


Camera accessories and tools

Camera Accessories
Find Vicon camera accessories including IQeye accessories, mounting, lenses, housings, power supplies and surge protection.

Calculation tools
Our online calculation tools can help you plan how these cameras will fit within your network infrastructure.
